GENTILIN - Qube 550/270 HS - Dry Air Comrpessor With Filter 400-50V-Hz
Gentilin Qube 550/270 HS Dry - Ultra Quiet Oil-Free Compressor with Membrane Dryer and Sterile Filter (270L Tank)
The Gentilin Qube 550/270 HS Dry is a premium compressor designed for professionals who require sterile, dry, and oil-free air with extremely low noise. Made in Italy, it combines advanced membrane drying technology, a high-efficiency sterile filter, and a large 270-liter tank, making it perfect for clinics, laboratories, medical facilities, and industries where the highest purity standards are needed.
Strong and continuous performance
The compressor is powered by a 4.0 kW (5.5 HP) motor with four cylinders, running at 1,400 rpm. It delivers an air intake of 660 L/min, with 360 L/min at 5 bar and 300 L/min at 8 bar, while reaching a maximum pressure of 10 bar. Thanks to its S1 duty cycle (100% on), the Qube 550/270 HS Dry can run continuously, providing a reliable air supply throughout the day.
Membrane dryer and sterile filter
Equipped with a membrane dryer, the compressor reduces the dew point to -40 °C, ensuring extremely dry compressed air. In addition, a sterile antibacterial filter removes particles as small as 0.01 µm, meeting the strict ISO 8573-1 Class 0-2-0 standard. This guarantees the highest level of air purity, suitable for applications where contamination cannot be tolerated.
Large 270L tank with epoxy coating
The unit comes with a 270-liter epoxy-coated tank, protected inside and outside against corrosion. The large tank ensures a generous air reserve, reducing cycle frequency and supporting long and demanding tasks.
Extremely low noise
Despite its high performance, the Qube 550/270 HS Dry operates at only 52 dB measured at 3 meters and 5 bar. This makes it one of the quietest compressors in its class, suitable for direct installation in clinics, labs, or workplaces where silence is essential.
Reliable and low-maintenance
The compressor is equipped with an hour meter as standard. An automatic condensate drain valve is available as an option. With the first maintenance required only after 10,000 hours, this model offers excellent reliability and low operating costs.
Technical highlights
-
Voltage: 400 V, 50 Hz - Absorption: 16 A
-
Motor: 4.0 kW (5.5 HP), 4 cylinders
-
Air intake: 660 L/min
-
Air delivery: 360 L/min at 5 bar, 300 L/min at 8 bar
-
Max pressure: 10 bar
-
Tank: 270 L, epoxy coated
-
Duty cycle: S1 100% continuous duty
-
Noise level: 52 dB
-
Dimensions: 1590 × 660 × 1550 mm
-
Weight: 275 kg (305 kg packaged)
The Gentilin Qube 550/270 HS Dry is the ultimate solution for professionals who need a quiet, oil-free compressor with sterile, moisture-free air for sensitive and demanding daily applications.
Catalog Download
Certifications Download
| Condensate Treatment | Membrane dryer | Dew Point -40°C |
|---|---|
| Particulate Treatment | 0.01µm | Sterilizing filter |
| Air purity class (ISO 8573-1) | 0-2-0 |
| Voltage (V) | 400.00 |
| Frequency (Hz) | 50.00 |
| Nominal rating (kW) | 4.00 |
| Nominal rating (HP) | 5.50 |
| Rotation speed (rpm) | 1,400.00 |
| Absorption (A) | 16.00 |
| Number of cylinders | 4 |
| Air intake (L/min) | 660.00 |
| Air Delivery (L/min @5 bar) | 360.00 |
| Air Delivery (L/min @8 bar) | 300.00 |
| Maximum pressure (bar) | 10.00 |
| Noise level (3.00m @ 5.00 bar) (dB(A)) | 52.00 |
| Duty cycle | S1 100% |
| Tank Coating | Epoxy (internal/external) |
| Tank capacity (lt) | 270.00 |
| First Maintenance (hours) | 10000 |
| Hour Meter | Included |
| Tank Automatic Drain Valve | Optional |
**All our products are brand new, shipped in the original packaging, and include manufacturer warranty**
