GENTILIN - Qube 550 - Air Compressor 400-50V-Hz
Gentilin Qube 550 - Ultra Quiet Oil-Free Compressor with Compact 10L Tank
The Gentilin Qube 550 is a powerful yet compact compressor designed for continuous work with exceptionally low noise. Built in Italy, it combines high airflow, a small and durable tank, and continuous-duty operation, making it perfect for clinics, laboratories, workshops, and industrial environments where silence and reliability are essential.
Strong and continuous performance
This model runs on a 4.0 kW (5.5 HP) motor with four cylinders, operating at 1,400 rpm. It provides an air intake of 660 L/min, with 430 L/min at 5 bar and 380 L/min at 8 bar, reaching a maximum pressure of 10 bar. Thanks to its S1 duty cycle (100% on), the Qube 550 can run all day without stopping, ensuring a constant and reliable supply of compressed air.
Compact 10L tank with epoxy coating
The compressor is fitted with a 10-liter epoxy-coated tank, treated both inside and outside for corrosion resistance. While compact in size, this tank provides a stable reserve of air and ensures smooth and efficient operation. Its smaller footprint makes it easy to place even in limited spaces.
Ultra-quiet operation
One of the most impressive features of the Qube 550 is its extremely low noise level of just 52 dB measured at 3 meters and 5 bar. This makes it quieter than most compressors of similar output, allowing it to be installed directly in clinics, labs, or offices without causing disturbance.
Reliable and low-maintenance
The Qube 550 comes with an hour meter for monitoring usage and scheduling service. An automatic condensate drain valve is available as an option. The first maintenance interval is after 10,000 hours, which keeps running costs low and ensures long-lasting performance.
Technical highlights
-
Voltage: 400 V, 50 Hz - Absorption: 6.5 A
-
Motor: 4.0 kW (5.5 HP), 4 cylinders
-
Air intake: 660 L/min
-
Air delivery: 430 L/min at 5 bar, 380 L/min at 8 bar
-
Max pressure: 10 bar
-
Tank: 10 L, epoxy coated
-
Duty cycle: S1 100% continuous duty
-
Noise level: 52 dB
-
Dimensions: Compact, tank-mounted (10 L)
-
First maintenance: 10,000 hours
The Gentilin Qube 550 is the ideal choice if you need a quiet, oil-free compressor with high airflow in a compact design, built for professional environments that demand constant performance.
Catalog Download
Certifications Download
| Condensate Treatment | - |
|---|---|
| Particulate Treatment | - |
| Air purity class (ISO 8573-1) | X-X-0 |
| Voltage (V) | 400.00 |
| Frequency (Hz) | 50.00 |
| Nominal rating (kW) | 4.00 |
| Nominal rating (HP) | 5.50 |
| Rotation speed (rpm) | 1,400.00 |
| Absorption (A) | 6.50 |
| Number of cylinders | 4 |
| Air intake (L/min) | 660.00 |
| Air Delivery (L/min @5 bar) | 430.00 |
| Air Delivery (L/min @8 bar) | 380.00 |
| Maximum pressure (bar) | 10.00 |
| Noise level (3.00m @ 5.00 bar) (dB(A)) | 52.00 |
| Duty cycle | S1 100% |
| Tank Coating | Epoxy (internal/external) |
| Tank capacity (lt) | 10.00 |
| First Maintenance (hours) | 10000 |
| Hour Meter | Included |
| Tank Automatic Drain Valve | Optional |
**All our products are brand new, shipped in the original packaging, and include manufacturer warranty**
