GENTILIN - Qube 550 HS - Dry Air Compressor With Filter 400-50V-Hz
Gentilin Qube 550 HS Dry - Ultra Quiet Oil-Free Compressor with Membrane Dryer and Sterile Filter (10L Tank)
The Gentilin Qube 550 HS Dry is a compact, high-performance compressor built for professionals who need sterile, dry, and oil-free air with minimal noise. Made in Italy, it combines advanced drying and filtration technology with continuous-duty operation, making it ideal for clinics, laboratories, and industries where the highest air purity is required.
Strong and continuous performance
This compressor is powered by a 4.0 kW (5.5 HP) motor with four cylinders, running at 1,400 rpm. It provides an air intake of 660 L/min, with 360 L/min delivered at 5 bar and 300 L/min at 8 bar, while reaching a maximum pressure of 10 bar. With its S1 duty cycle (100% on), the Qube 550 HS Dry can operate all day without interruption, delivering a constant and reliable flow of air.
Membrane dryer and sterile filter
Equipped with a membrane dryer, the compressor reduces the dew point to -40 °C, ensuring extremely dry air. It also features an antibacterial sterile filter that removes particles as small as 0.01 µm, meeting the strict ISO 8573-1 Class 0-2-0 standard. This makes it suitable for applications where sterile air is required, such as medical, dental, pharmaceutical, and food production environments.
Compact 10L tank with epoxy coating
The compressor includes a 10-liter epoxy-coated tank, resistant to corrosion both inside and outside. Despite its compact size, the tank ensures stable air storage and reliable performance during continuous use.
Extremely low noise
Even at this performance level, the Qube 550 HS Dry operates at only 52 dB measured at 3 meters and 5 bar. This ultra-low noise output makes it one of the quietest compressors in its category, suitable for direct installation in clinics, labs, or offices.
Standard features
The compressor comes with an hour meter for monitoring workloads and an optional automatic condensate drain valve. With a first maintenance interval of 10,000 hours, it offers long-term reliability and low operating costs.
Technical highlights
-
Voltage: 400 V, 50 Hz - Absorption: 16 A
-
Motor: 4.0 kW (5.5 HP), 4 cylinders
-
Air intake: 660 L/min
-
Air delivery: 360 L/min at 5 bar, 300 L/min at 8 bar
-
Max pressure: 10 bar
-
Tank: 10 L, epoxy coated
-
Duty cycle: S1 100% continuous duty
-
Noise level: 52 dB
-
Dimensions: Compact, tank-mounted (10 L)
-
First maintenance: 10,000 hours
The Gentilin Qube 550 HS Dry is the ultimate solution for professionals who need a quiet, oil-free compressor with sterile and moisture-free air in a compact format for continuous daily use.
Catalog Download
Certifications Download
| Condensate Treatment | Membrane dryer | Dew Point -40°C |
|---|---|
| Particulate Treatment | 0.01µm | Antibacterial filter |
| Air purity class (ISO 8573-1) | 0-2-0 |
| Voltage (V) | 400.00 |
| Frequency (Hz) | 50.00 |
| Nominal rating (kW) | 4.00 |
| Nominal rating (HP) | 5.50 |
| Rotation speed (rpm) | 1,400.00 |
| Absorption (A) | 16.00 |
| Number of cylinders | 4 |
| Air intake (L/min) | 660.00 |
| Air Delivery (L/min @5 bar) | 360.00 |
| Air Delivery (L/min @8 bar) | 300.00 |
| Maximum pressure (bar) | 10.00 |
| Noise level (3.00m @ 5.00 bar) (dB(A)) | 52.00 |
| Duty cycle | S1 100% |
| Tank Coating | Epoxy (internal/external) |
| Tank capacity (lt) | 10.00 |
| First Maintenance (hours) | 10000 |
| Hour Meter | Included |
| Tank Automatic Drain Valve | Optional |
